Engine type 1-Cylinder/4-st/Compulsive-Cooled
Displacement 49.5
Mini Idle speed（r/min) 1600±150
Maximum power and cor.speed（kw/r/min) 2.1/6500
Maximum torque and cor.speed（N.m/r/min) 3.1/6000
Bore*stroke（mm*mm) 39*41.5
Lubrication method Press/Splash
Economical Fuel Consumption(L/100KW) 2.0
Start Electricity/Kick
Ignition C.D.I
Drive Rear Dive
Transmission Belt
Clutch Auto/Dry/Multiplate
Gear Type Infinite Variable Speed
Level /
Dimension (L*W*H)mm 1850*700*1300
Steering Angel 45°
Clearance(mm) 140
Wheelbase(mm) 1320
N.W.(kg) 87
G.W.(kg): 150 92
MAX Load (kg) 100
MAX.Carriers 2
FR.brake DISC
RR.Brake DRUM
MAX.Speed（km/h） ≥60
F.WHEEL 120/70-12
R.WHEEL 120/70-12
Tire Type VACUUM
L Fuel tank capacity: 4.5
