INSULATING GLASS MOLECULAR SIEVE
Application
Insulating glass molecular Sieve is used specially for adsorption of the water vapor in insulating glass to improve sound insulation and heat insulation of glass.
|
Properties |
Measure
Unit |
Spherical |
|
Diameter |
mm |
0.5-0.9 |
1.0-1.5 |
1.2-1.8 |
1.5-2.0 |
1.5-2.5 |
|
Static Water Adsorption |
≥mg/g |
200 |
200 |
200 |
200 |
200 |
|
Bulk Density |
g/ml |
0.73±0.02 |
0.73±0.02 |
0.73±0.02 |
0.73±0.02 |
0.73±0.02 |
|
Crush Strength |
≥N |
|
15 |
18 |
20 |
25 |
|
△t(25g-25cc) |
≥oC |
35 |
35 |
35 |
35 |
35 |
|
Particle |
≥% |
98 |
98 |
98 |
98 |
98 |
|
Wear Rate |
≤% wt |
0.1 |
0.1 |
0.1 |
0.1 |
0.1 |
|
Package Moisture |
≥% wt |
1.0 |
1.0 |
1.0 |
1.0 |
1.0 |
Storage:
The molecular sieve shall be stored at room temperature, in which the relative humidity is not exceed 90%, and be not exposed in air, and prevented against water, acids and alkalies.
Package:
25kg/carton box
25kg/carton box, 60 cartons/pallet, 10 pallets, 600carton/ 20’ container
Net weight 15000kg/20’ container, gross weight 15600kg/20’ container
1000 carton/40’container, Net weight 25000kg/40’ container, gross weight 26000kg/40’ container
40L/25kg wooden barrel
200L/150kg iron drum, 4 drums with one pallet
1.2ton/big compound super pack bag
1.2ton/super pack,10 super packs/20’container,12000kg/20’container,20 super packs /40’container,
24000kg/40’container, super pack: 2 meter height x1.1meter width x 1.1meter width=2.42CBM
|
