MOLECULAR SIEVE MS

Price:	Negotiable
Effective Period:	Valid permanently
Place or Origin:	Shanghai, China
Supply Quantity:	No Limited
Number of Browsing:

Need more product details? Contact Now!

Detailed Product Description

Type A

3A

3A EPG

Activated Powder 3A

4A

4A DG

Activated Powder 4A

5A

Activated Powder 5A

Type X

Molecular Sieve 10X

Molecular Sieve 13X APG

Molecular Sieve 13X HP

Molecular Sieve 13X PG

Activated Powder 13X

Specialized Molecular Sieve

For refrigerant and air conditioner

XH5

XH6

XH7

XH9

XH11

Air Brake Molecular Sieve for automobile air desicator

For insulating glass 3A

PSA molecular Sieve for extracting hydrogen 5A PSA H

PSA, VPS rich oxygen molecular Sieve 5A PAS O, 5A VPS O.

For deodorization of aerosol RK-29

Product Specification

Molecular Sieves Type A

l Molecular Sieve 3A

Applications

It is used for commercial dehydration of unsaturated hydrocarbon streams such as cracked gas, acetylene, propylene, and butadiene. It is also used for dehydration of alcohol and solvents.

Properties	Measure Unit	Spherical			Cylindrical
Diameter	mm	1.6-2.5	3-5	5-8	1.6	3.2
Static Water Adsorption	≥ mg/g	210	210	210	210	210
CO₂ Adsorption	≤ %wt	2.0	2.0	2.0	1.0	1.0
Bulk Density	g/ml	0.70±0.02	0.68±0.02	0.66±0.02	0.68±0.02	0.66±0.02
Crush Strength	≥ N	30	80	110	35	70
Wear Rate	≤% Wt	0.1	0.1	0.1	0.2	0.2
Package Moisture	≤% Wt	1.0	1.0	1.0	1.0	1.0

l Molecular Sieve 3A EPG

Applications

Type 3A EPG is used for dehydration of acetylene, oil cracked gas.

Properties	Measure Unit	Cylindrical
Diameter	mm	1.6	3.2
Static Water Adsorption	≥mg/g	210	210
CO₂ Adsorption	≤ %	1.0	1.0
Bulk Density	g/ml	0.68±0.02	0.66±0.02
Crush Strength	≥ N	42	80
Wear Rate	≤% Wt	0.2	0.2
Package Moisture	≤% Wt	1.0	1.0

l Activated Powder 3A

Applications

It is used commercial for insulating glass sealant strips and solvents.

Properties	Measure Unit	Specification
Form	----	Powder
Pore Diameter	A	3
Whiteness	≥%	90
Particle Diameter	μm	2-4
Static Water Adsorption	≥mg/g	230
PH	≤	11
Gravity	≥g/ml	0.44
Package Moisture	≤%wt	2

l Molecular Sieve 4A

Applications

It is used commercially for dehydration of various gases and liquids, refrigerant, medicine, electronic components and changeable substance, purification of argon gas.

Properties	Measure Unit	Spherical			Cylindrical
Diameter	mm	1.6-2.5	3-5	5-8	1.6	3.2
Static Water Adsorption	≥mg/g	215	215	215	215	215
Methanol Adsorption	≥mg/g	140	140	140	140	140
Bulk Density	g/ml	0.70±0.02	0.68±0.02	0.66±0.02	0.68±0.02	0.66±0.02
Crush Strength	≥ N	35	80	140	32	80
Wear Rate	≤% wt	0.1	0.1	0.1	0.2	0.2
Package Moisture	≤% wt	1.0	1.0	1.0	1.0	1.0

l Molecular Sieve 4A DG

Applications

It is used commercially in deep drying natural gas alkane, it is also used for dehydration of various gases and liquids, refrigerant, medicine, electronic components and changeable substance, purification of argon gas.

Properties	Measure Unit	Spherical	Cylindrical
Diameter	mm	3-5	1.6	3.2
Static Water Adsorption	≥ mg/g	215	215	215
Methanol Adsorption	≥ mg/g	140	140	140
Bulk Density	g/ml	0.68±0.02	0.68±0.02	0.66±0.02
Crush Strength	≥ N	100	40	90
Wear Rate	≤ % wt	0.1	0.2	0.2
Package Moisture	≤% wt	1.0	1.0	1.0

l Activated Powder 4A

Applications

Available in powder for dehydration of coating and polyurethane glue etc.

Properties	Measure Unit	Specification
Form	----	Powder
Pore Diameter	A	4
Whiteness	≥%	90
Particle Diameter	μm	2-4
Static Water Adsorption	≥mg/g	240
PH		≤11.5
Gravity	≥g/ml	0.44
Package Moisture	≤%wt	2

l Molecular Sieve 5A

Applications

Used commercially in drying and refining air, petroleum, natural gas and gas in other industries.

Properties	Measure Unit	Spherical			Cylindrical
Diameter	mm	1.6~2.5	3~5	5~8	1.6	3.2
Static Water Adsorption	≥ mg/g	210	210	210	210	210
n-hexane Adsorption	≥ mg/g	120	120	120	120	120
Bulk Density	g/ml	0.72±0.02	0.70±0.02	0.68±0.02	0.68±0.02	0.66±0.02
Crush Strength	≥ N	35	80	130	35	70
Wear Rate	≤ %wt	0.1	0.1	0.1	0.2	0.2
Package Moisture	≤ %wt	1.0	1.0	1.0	1.0	1.0

l Activated Powder 5A

Applications

Available in powder for dehydration of coating and solvents.

Properties	Measure Unit	Specification
Form	----	Powder
Pore Diameter	A	5
Whiteness	≥%	90
Particle Diameter	μm	2-4
Static Water Adsorption	≥mg/g	240
PH	≤	11
Gravity	≥g/ml	0.40
Package Moisture	≤%wt	2

Molecular Sieves Type X

l Molecular Sieve 10X

Applications

Used commercially for natural gas sweetening (removal of H₂S and mercaptons) and dewaxing in oil refining facility.

Properties	Measure Unit	Spherical		Cylindrical
Diameter	mm	1.6-2.5	3-5	1.6	3.2
Static Water Adsorption	≥mg/g	260	260	260	260
Benzene Adsorption	≥mg/g	180	180	180	180
Bulk Density	g/ml	0.64±0.02	0.62±0.02	0.58±0.02	0.58±0.02
Crush Strength	≥N	25	60	20	40
Wear Rate	≤% wt	0.1	0.1	0.2	0.2
Package Moisture	≤% wt	1.0	1.0	1.0	1.0

l Molecular Sieve 13X APG

Applications

Used commercially for air plant feed purification (simultaneous removal of H₂O and CO₂ ) and general gas drying.

Properties	Measure Unit	Spherical		Cylindrical
Diameter	mm	1.6-2.5	3-5	1.6	3.2
Static Water Adsorption	≥ mg/g	270	270	270	270
CO₂ Adsorption	≥ mg/g	180	180	180	180
Bulk Density	g/ml	0.67±0.02	0.66±0.02	0.62±0.02	0.62±0.02
Crush Strength	≥ N	30	80	30	65
Wear Rate	≤ % wt	0.10	0.10	0.10	0.10
Package Moisture	≤ % wt	1.0	1.0	1.0	1.5

l Molecular Sieve 13X HP

Applications

Used commercially for air plant feed purification and PSA oxygen generation process.

Properties	Measure Unit	Spherical
Diameter	mm	0.5-1.0	1.6-2.5
Static Water Adsorption	≥ mg/g	285	285
CO₂ Adsorption	≥ mg/g	190	195
Bulk Density	g/ml	0.64±0.02	0.62±0.02
Crush Strength	≥ N		20
Wear Rate	≤ % wt	1.0	1.0
Package Moisture	≤ % wt	1.0	1.0

l Molecular Sieve 13X PG

Applications

Used commercially for desulphurization of liquefied petroleum gas. It is also used for dehydration of gases and liquids.

Properties	Measure Unit	Spherical			Cylindrical
Diameter	mm	1.6-2.5	3-5	5-8	1.6	3.2
Static Water Adsorption	≥mg/g	260	260	260	260	260
CO₂ Adsorption	≥mg/g	175	175	175	175	175
Bulk Density	g/ml	0.67±0.02	0.66±0.02	0.64±0.02	0.62±0.02	0.60±0.02
Crush Strength	≥ N	25	80	120	25	64
Wear Rate	≤% wt	0.1	0.1	0.1	0.2	0.2
Package Moisture	≤% wt	1.0	1.0	1.0	1.0	1.0

l Activated Powder 13X

Applications

Available in powder for dehydration in coating industry and paint industry.

Properties	Measure Unit	Specification
Form	----	Powder
Pore Diameter	X	13
Whiteness	≥%	90
Particle Diameter	μm	1-4
Static Water Adsorption	≥% wt	260
Gravity	≥g/ml	0.33
PH	≤	11.5
Package Moisture	≤%wt	3.0

Specialized Molecular Sieve

l For refrigerant and air conditioner

XH5

Applications

Used commercially for dehydration and drying of refrigerants R12, R22.

Properties	Measure Unit	XH-5
Diameter	mm	1.6---2.5
Bulk Density	g/ml	0.80±0.02
Static Water Adsorption	≥ mg/g	210
Dynamic water Adsorption	≥ mg/g	60
Crush Strength	≥ N	80
Wear Rate(dry)	≤ % wt	0.1
Wear Rate(humidity)	≤ % wt	3.0
Package Moisture	≤ % wt	1.0

l For refrigerant and air conditioner

XH7

XH9

XH11

Applications

RG-7 is used for dehydration and drying of new refrigerants R-134a in household and commercial refrigerators, iceboxes and air conditioners. It is also used for specialized refrigerants such as butane in "green" refrigerators.

RG-9 is used commercially in drying refrigerants in air conditioners, iceboxes and refrigerators in cars, station wagons, refrigerating trucks, trains and shipper.

RG-11 is available in bead for dehydration and drying of refrigerants R407c, R-410A.

Properties	Measure Unit	XH7	XH9	XH11
Diameter	mm	1.6 ~ 2.5	1.6 ~ 2.5	1.6 ~ 2.5
Bulk Density	g/ml	0.85±0.02	0.85±0.02	0.85±0.02
Static Water Adsorption	≥ mg/g	175	170	165
Dynamic water Adsorption	≥ mg/g	60	60	60
Crush Strength	≥ N	80	80	80
Wear Rate(dry)	≤ % wt	0.1	0.1	0.1
Wear Rate(humidity)	≤ % wt	3.0	3.0	3.0
Package Moisture	≤ % wt	1.0	1.0	1.0
Test of compatibity with R-134a
Fluorine content before test	% wt	0.018	0.018	Difluoromethane Adsorption 0.01% wt
Fluorine content after test	% wt	0.018	0.018	Difluoromethane Adsorption 0.01% wt

l For automobile air desiccator

4A air brake molecular sieve

Applications

Used specially for desiccation of automobile air system.

Properties	Measure Unit	Spherical
Diameter	mm	2~2.5
Static Water Adsorption	≥ mg/g	210
Methanol Adsorption	≥ mg/g	140
Bulk Density	g/ml	0.75±0.04
Crush Strength	≥ N	80
Wear Rate	≤ %wt	0.1
Package Moisture	≤ %wt	1.0

l For insulating glass

Application

Insulating glass molecular Sieve is used specially for adsorption of the water vapor in insulating glasses to improve sound insulation and heat insulation of glass.

Properties	Measure Unit	Spherical
Diameter	mm	0.5-1.0	1.0-1.6	1.2-1.8	1.5-2.0	1.6-2.5
Static Water Adsorption	≥mg/g	200	200	200	200	200
Bulk Density	g/ml	0.73±0.02	0.73±0.02	0.73±0.02	0.73±0.02	0.73±0.02
Crush Strength	≥N		15	18	20	25
△t(25g-25cc)	≥oC	35	35	35	35	35
Particle	≥%	98	98	98	98	98
Wear Rate	≥% wt	0.1	0.1	0.1	0.1	0.1
Package Moisture	≥% wt	1.0	1.0	1.0	1.0	1.0

l PSA molecular Sieve for extracting hydrogen

5A PSA H

Applications

It is used for PSA hydrogen separation and CO refining.

Properties	Measure Unit	Spherical
Diameter	mm	1.6-2.5
Static Water Adsorption	≥ mg/g	260
CO Adsorption	≥ ml/g	30
N₂Adsorption	≥ ml/g	10.2
n-hexane Adsorption	≥ mg/g	135
Bulk Density	≥ g/ml	0.78±0.04
Crush Strength	≥ N/P	40
Wear Rate	%wt	0.3
Package Moisture	≤ %wt	1.5

l PSA, VPS rich oxygen molecular Sieve

512 PSA O, 5A VPS O

Applications:

Except for general properties of molecular Sieve 5A, it is mainly used for PSA or VPS rich oxygen generation.

Properties	Measure Unit	Spherical
Diameter	mm	0.6-0.9	1.6-2.5
Static Water Adsorption	≥mg/g	265	265
N₂ Adsorption	≥ml/g	10.8	10.8
Separation value of N2 & O2	≥	3.2	3.2
Bulk Density	g/ml	0.74±0.02	0.72±0.02
Crush Strength	≥N/P		40
Wear Rate	≤%wt	0.3	0.3
Package Moisture	≤%wt	1.0	1.0

l For deodorization of aerosol RK-29

Applications

It is used for desulphurization of liquefied petroleum gas.

Properties	Measure Unit	Cylindrical
Diameter	mm	1.6
Static Water Adsorption	≥ mg/g	215
n-hexane Adsorption	≥ mg/g	120
Bulk Density	≥ g/ml	0.64±0.02
Crush Strength	≥ N	35
Wear Rate	≤ %wt	0.2
Package Moisture	≤ %wt	1.5
